Dell EMC Connectrix ED-DCX7-4B Enterprise
Base price
Description
| General | |
|---|---|
| Device Type | Switch - managed |
| Enclosure Type | Rack-mountable 8U |
| Subtype | Fibre Channel |
| Capacity | Maximum frame size: 2112 ¦ Frame buffers: 24000 |
| Fibre Channel | FC-PH |
| Remote Management Protocol | SNMP 1, SNMP 3, HTTP, HTTPS, SMI-S, SSH, SSH-2, CLI, SCP, SFTP, LDAP |
| Encryption Algorithm | FIPS 140-2, TLS 1.2, TLS 1.3 |
| Authentication Method | RADIUS, TACACS+, DH-CHAP, FCAP |
| Features | CWDM, Syslog support, IP address filtering, DWDM, Registered State Change Notification (RSCN) support, Class of Service (CoS), Extended Fabric, Adaptive Networking, Fabric Configuration Server (FCS), Fabric Shortest Path First (FSPF), Fabric-Device Management Interface (FDMI), Role-Based Access Control (RBAC), Dynamic path selection (DPS), Simple Name Server (SNS), Flow Vision, Advanced Zoning, port trunking |
| Expansion / Connectivity | |
|---|---|
| Interfaces | USB ¦ Management (LAN) ¦ Serial (console) |
| Expansion Slots | 4 (total) / 4 (free) x expansion slot |
| Power | |
|---|---|
| Power Device | Internal power supply (not installed) |
| Max Supported Qty | 4 |
| Software / System Requirements | |
|---|---|
| Software Included | Advanced Web Tools, Brocade SANnav Management Portal, Brocade SANnav Global View |
| Dimensions & Weight | |
|---|---|
| Width | 17.2 in |
| Depth | 24 in |
| Height | 13.6 in |
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 93% (non-condensing) |
| Min Storage Temperature | -13 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 10 - 93% (non-condensing) |
