Chipset |
Intel® C624
|
Mainboard type |
D3383-B
|
Product Type |
Dual Socket Rack Server
|
Processor |
Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel ® Xeon® Platinum 8xxx processor
1 - 2 x Intel® Xeon® Processor Scalable Family |
Memory |
8 GB - 8 TB, DIMM (DDR4 / DDR-T for non-volatile memory
modules)
|
Memory slots |
24 (12 DIMMs per CPU, 6 channels with 2 slots per channel)
|
Memory protection |
Advanced ECC, Memory Scrubbing, SDDC, Rank sparing memory
support, Memory Mirroring support
|
Drives (optional) |
DVD supermulti, ultraslim, SATA I
|
PCI-Express 3.0 x8 |
1 x Low profile (2nd processor required for slot 4)
|
PCI-Express 3.0 x16 |
3 x Low profile (2nd processor required for slot 4); 1x16 if fh
slot selected
|
Accessible drive bays |
1 x 5.25/0.4-inch for CD-RW/DVD
|
Optional accessible drives |
Ultra slim 9.5mm optical drive (optional)
n/a Not for 10 x 2.5-inch base unit. All possible options described in relevant system configurator. |
Storage drive bays |
up to 8 x 2.5-inch, 10 x 2.5-inch or 4 x 3.5-inch baseunit
up to 4x 3.5" (LFF) hot plug drives (SAS/SATA) up to 4x 2.5" (SFF) hot plug drives (SAS/SATA); option for upgrade to 8x 2.5" (SFF) hot plug drives up to 8x 2.5" (SFF) hot plug drives (SAS/SATA) up to 10x 2.5" (SFF) hot plug drives (SAS/SATA); thereof up to 4x bays prepared for 2.5" PCIe SSD up to 10x 2.5" (SFF) hot plug drives (SATA or PCIe SSD) |
LAN Controller |
2 x 1 Gbit/s onboard, Optional DynamicLoM OCP adaptors:, 4 x 1
Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10
Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28 (only for
10x HDD/SSD base unit)
|
Remote Management |
Integrated Remote Management Controller (iRMC S5, 512 MB
attached memory incl. graphics controller), IPMI 2.0 compatible
|
USB ports |
5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base unit
with 10x 2.5" drives 1x USB 2.0 front only
|
Graphics |
2 x VGA (thereof 1x front optional - not for base unit with 10x
2.5" drives)
|
Management LAN (RJ45) |
1 x dedicated management LAN port for iRMC S5 (10/100/1000
Mbit/s), Management LAN traffic can be switched to shared
onboard LAN controller port, speed and connector is related to
installed interface card.
|
Trusted Platform Module (TPM) |
Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)
|
Power supply configuration |
1 x hot-plug power supply or 2 x hot-plug power supply for
redundancy
|
Active power (max. configuration) |
883 W
|
Weight |
up to 16 kg
|
Rack (W x D x H) |
483 mm (Bezel) / 435mm (Body) x 770.7 x 43 mm
|
Mounting Depth Rack |
748.2 mm
|
DC Infrastructure Management |
Infrastructure Manager (ISM)
Essential Edition Advanced Edition |
Server Management |
Infrastructure Manager (ISM)
Essential Edition Advanced Edition, ServerView Suite |
