Processor Type Intel®
Processor family 3rd Generation Intel® Xeon® Scalable Processors
Processor core available 16 to 40 core, depending on processor
Maximum memory
8.1 TB - RDIMM (4 TB per processor), 11.2 TB - LRDIMM and Intel® Optane™
(5.6 TB per processor with 8x
LRDIMM and 8x 512 GB Intel Optane)
Memory slots 32
Memory type HPE DDR4 SmartMemory
Persistent Memory Type Intel® Optane™ Persistent Memory for HPE
Persistent Memory Media Capacity 128 GB - 512 GB
NVDIMM type Optional: Intel® Optane™ Persistent Memory for HPE
NVDIMM capacity 128 GB - 512 GB
Memory protection features RAS – Advanced ECC, online spare, mirroring, combined channel (lockstep) functionality, and HPE Fast Fault Tolerant Memory (ADDDC); Intel Optane Persistent Memory
Drive supported 8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD, 2 M.2 SATA SSD standard on primary riser, depending on configuration, 8 SFF mid-tray optional, 6 SFF rear drive optional or 4 LFF mid tray optional, 3 LFF rear-drive optional and 2 SFF or 2 Dual UFF rear-drive optional, 20 SFF NVMe optional, NVMe support via Express Bay will limit maximum drive capacity, depending on model
Infrastructure management HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional, requires licenses)
System fan features Hot-plug redundant fans, standard
Power supply type Dual hot-plug redundant 1+1 HPE Flexible Slot Power Supplies (2.6”)
Expansion slots 8, for detailed descriptions refer to the QuickSpecs
Network controller Intel I350 1GbE 4 port Base-T OCP3 adapter or Broadcom 57416 10GbE 2 port Base-T adapter and/or optional network adapters depending on model
Storage controller HPE SR932i-p and/or HPE SR416i-a and/or HPE MR216i-a and/or HPE MR416i-a and/or HPE MR216i-p and/or HPE MR416i-p and/or HPE Smart Array P816i-a SR and/or HPE Smart Array E208i-a SR and/or HPE Smart Array P408i-a SR and/or HPE Smart Array E208i-p SR and/or HPE Smart Array E208e-p SR and/or HPE Smart Array P408e-p SR and/or HPE Smart Array P408i-p SR
Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit http://www.hpe.com/support
Processor Name 3rd Generation Intel® Xeon® Scalable Processors
Processor number 1 or 2
Processor speed 3.1 GHz maximum, depending on processor
Memory, standard 16 GB (1 x 16 GB) RDIMM
Included hard drives None ship standard, SFF and LFF drives supported
Optical drive type Optional DVD-ROM Optional via Universal Media Bay External support only
Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Form factor 2U
