Form Factor/Height
|
Standard width blade; up to 14x supported in the Flex
Enterprise Chassis
|
Processors
|
Up to 2x 3rd generation Intel® Xeon®
Scalable processors up to 205W (up to 250W with Special Bid)
|
Memory
|
Up to 2TB in 16x slots using 128GB DIMMs; Memory operates at
3200MHz; supports Intel® Optane™ Persistent Memory
200 Series module (PMem)
|
Expansion Slots
|
Up to 2x PCIe 4.0 x16 mezzanine slots for Ethernet and Fibre
Channel adapters
|
Internal Storage
|
Either 6x EDSFF bays supporting NVMe SSDs, 2x 2.5" bays
supporting SAS/SATA drives, or 2x 2.5" bays supporting
NVMe/SATA drives; plus 2x M.2 SATA/NVMe boot drives (optional
RAID 0,1)
|
Network Interface
|
2x slots for adapters, 2-port or 4-port 10GbE, 4-port 25GbE or
2-port 50GbE; FCoE/iSCSI support
|
RAID Support
|
Onboard RAID with Intel® VROC for NVMe and SATA;
optional basic RAID adapter (12Gbps SAS/SATA); optional
advanced RAID adapter (12Gbps SAS/SATA with 2GB flash-backed
cache)
|
Power
|
Hot-swap/redundant power supplies housed in the chassis
|
Systems Management
|
Lenovo XClarity Controller, XClarity Administrator, XClarity
Integrator plugins, and XClarity Energy Manager
|
Security and Availability Features
|
Lenovo ThinkShield; operating temperature up to 40°C (with
limitations)
|
OS Support
|
Microsoft, SUSE, Red Hat, VMware. Visit
lenovopress.com/osig
a> for details.
|
Limited Warranty
|
1-year and 3-year customer replaceable unit and onsite service,
next business day 9x5; optional service upgrades
|
