Form Factor | 1U rack; Height: 43mm (1.7 inches), width: 435mm (17.1 inches), depth: 498mm (19.6 inches) |
---|---|
Processor | 1x Intel® Xeon® processor E-2300 or 1x Intel® Pentium® processor, up to 8 cores at 95W |
Drive Bays |
4x 3.5-inch simple-swap SATA drives
3x 3.5-inch simple-swap SATA drives plus 1x 3.5-inch simple-swap NVMe drive 4x 3.5-inch hot-swap SATA/SAS drives 8x 2.5-inch hot-swap SATA/SAS drives 10x 2.5-inch hot-swap SATA/SAS drives Optional SATA Mirrored M.2 boot drive kit; installs in a PCIe slot |
Memory | Up to 128GB in 4x DIMM slots using 32GB UDIMMs 3200MHz TruDDR4 |
Expansion Slots |
2x PCIe Gen4 x8 slots or 1x PCIe Gen4 x16 slot
1x PCIe Gen4 x8 (x4 interface) internal RAID slot |
Network Interface | 2x GbE on-board ports (Broadcom BCM5720); 1x GbE port dedicated for XCC management |
Ports |
Front: 1x USB 3.2 Gen 1 (5Gbps), 1x USB 2.0 port for local
management using the XCC Mobile app
Rear: 2x USB 3.2 G2 (10Gb) ports, 2x RJ45 Gigabit Ethernet ports, 1x 1GbE dedicated XCC port for remote management, 1x Serial port and 1x VGA port |
RAID Support | Intel® VROC Software RAID supports simple swap and hot swap Multiple RAID configurations (common with other ThinkSystem servers) |
Power Supplies | Supports a single fixed power supply or a redundant pair of hot-swap power supplies |
Systems Management and Security | Lenovo XClarity Controller; Embedded TPM 2.0;Optional front security bezel |
OS Support | Microsoft Windows Server 2022, Red Hat, SUSE, and VMware ESXi. Visit lenovopress.com/osig for more information. |
Limited Warranty | 1-year or 3-year warranty |
