Form Factor/Height |
3U Rack-mount with three modules |
---|---|
Processors |
2x 3rd Gen Intel® Xeon® Scalable processors per node |
Memory |
Up to 4TB using 32x 128GB 3DS RDIMMs per node
|
Base Module |
Up to 4x double-wide, full-height, full-length FHFL GPUs
each PCIe Gen4 x16
|
Dense Module |
Up to 8x double-wide, full-height, full-length GPUs each
PCIe Gen4 x16 on PCIe switch
|
HGX Module |
NVIDIA HGX A100 4-GPU with 4x NVLink connected SXM4 GPUs
|
RAID Support |
SW RAID standard; Intel® Virtual RAID on CPU (VROC), HBA or HW RAID with flash cache options |
I/O Expansion |
Up to 4x PCIe Gen4 x16 adapters (2 front or 2-4 rear) and 1x PCIe Gen4 x16 OCP 3.0 mezz adapter (rear) depending on the configuration |
Power and Cooling |
Four N+N redundant hot-swap PSUs (up to 2400W Platinum)
|
Management |
Lenovo XClarity Controller (XCC) and Lenovo Intelligent Computing Orchestration (LiCO) |
OS Support |
Red Hat Enterprise Linux, SUSE Linux Enterprise Server,
Microsoft Windows Server, VMware ESXi
|
Limited Warranty |
1-year and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades |
