EMC VNX

Base price
Description

BLOCK

COMPONS

VNX5200

VNX5400

VNX5600

VNX5800

VNX7600

VNX8000

Min/ Max Drives

4/125

4/250

4/500

4/750

4/1000

4/1500

Max FAST Cache

600GB

1TB

2TB

3TB

4.2TB

4.2TB

Array Enclosure

3U Disk Processor Enclosure (Holds 25x2.5” SAS/Flash drives)

4UStorage Processor Enclosure (No drives)

Drive Enclosure Options

(Disk Array Enclosure-DAE)

All model support 2U 25 drive trays for 2.5” SAS/Flash drives

All model support 3U 15 drive trays for 3.5” SAS/Flash drives

NA VNX5400 and above support 4U 60 drive trays for3.5” SAS/Flash drives

Standby Power

System

Onboard batteries, one for each Storage Processor

2x2Urackmounted

2.2KWLi-Ion

Raid Options

0/1/10/3/5/6

CPU/Memory per Array

2xIntelXeon

E5-26004-Core

1.2GHz/32GB

2xIntelXeon

E5-26004-Core

1.8GHz/32GB

2xIntel Xeon

E5-26004-Core

2.4GHz/48GB

2xIntelXeon

E5-26006-Core

2.0GHz/64GB

2xIntelXeon

E5-26008-

Core2.2GHz

/128GB

4xIntel Xeon E5-26008-Core2.7GHz/256GB

Max Block

UltraFlex™ IO

Modules per Array

6

8

10

10

10

22

Embedded IO

Ports per Array

2 x 4 lane SAS ports (for BE Connection)

NA

Base 6Gb/s SAS BE Buses per Array

2x4 Lane

2x4 Lane

2x4 Lane

2x4 Lane

2x4 Lane

8x4 Lane

Max 6 Gb/s SAS BE Buses per Array

2 x 4 Lane

2 x 4 Lane

6x4 Lane or 2x4 Lane + 2x8 Lane

6x4 Lane or 2x4 Lane + 2x8 Lane

6x4 Lane or 2x4 Lane + 2x8 Lane

16x4 Lane or

8x8 Lane

Max Total Ports per Array

28

36

44

44

44

88

2/4/8Gb/s FC MAX Ports Per Array

24

32

40

40

40

72

1GBase T iSCSI Max Total Ports per Array

16

16

16

16

16

16

10 GbE iSCSI Max

Total Ports per Array

12

16

16

16

16

16

Max FCoE Total Ports per Array

12

16

20

20

20

36

FILE COMPONENTS**

# File Data Movers

1- 3

1- 4

1- 4

2- 6

2- 8

2- 8

# Control Stations

1 x 1U Server standard,

2nd x 1U Server optional

Data Mover: CPU/Memory

Intel Xeon 5600/6GB

Intel Xeon 5600/6GB

Intel Xeon 5600/12GB

Intel Xeon 5600/12GB

Intel Xeon 5600/24GB

Intel Xeon 5600/24GB

Max File Ultra Flex IO Modules per Data Mover

3

3

3

4

4

5

Min/Max 2 /4/8 Gb/s FC Ports per Data Mover

4

4

4

4

4

4

Max IP Ports per Data Mover

8

8

8

12

12

16

Max 1GBaseT Ports per Data Mover

8

8

8

12

12

16

Max 10GbE Ports per Data Mover

4

4

4

6

6

8

Management

LAN 2x 10/ 100/ 1000 Copper GbE

FUNCTIONAL LIMITS

Max Raw Capacity

500TB

1,000TB

2,000TB

3,000TB

4,000TB

6,000TB

Max SAN Hosts

1,024

1,024

1,024

2,048

4,096

8,192

Max Number of Pools

15

15

20

40

40

60

Max Number of LUNs (Cool)

1,000

1,000

1,000

2,000

3,000

4,000

Max Number of LUNs (Classic)

2048

2048

2048

4096

4096

8192

Max Pool Based LUN Size

256 TB (Virtual Pool LUN)

256 TB (Virtual Pool LUN)

256 TB (Virtual Pool LUN)

256 TB (Virtual Pool LUN)

256TB (Virtual Pool LUN)

256TB (Virtual Pool

LUN)

Max File System

Size

16 TB

16 TB

16 TB

16 TB

16 TB

16 TB

Maximum Usable

File Capacity per

Data Mover

256 TB

256 TB

256 TB

256 TB

256 TB

256 TB
